Video Wall Controller 1x4 HDMI 1080p

Product Overview

Video Wall Controller 1x4 HDMI 1080p - The CT398/04 controller represents an advanced engineering solution for the configuration and management of video walls. Designed to maximize flexibility and efficiency in multi-screen environments, this device is indispensable for integrating complex audiovisual systems.

Benefits include greater flexibility in presenting information, improved workflow management through simultaneous display of multiple sources, and greater efficiency in business presentations. Furthermore, the ease of use and intuitive configuration allow for rapid implementation, ensuring an immediate and professional visual impact. With the Video Wall Controller 2x2, you get a powerful tool to improve visual communication and optimize information sharing in various contexts.

Advanced Technical Features

🔹 High Connectivity : Equipped with 1 HDMI input and 4 HDMI outputs, the controller supports high-definition signal transmission, ensuring the fidelity and integrity of visual content across different displays.

🔹 Higher Resolution Support : The device manages resolutions up to 1920x1200@60Hz, ensuring the sharpness and precision of visual details, fundamental in professional and commercial applications.

🔹 Custom Configurability : With 8 splicing modes available, adjustable via RS-232 or dip switches, the controller offers unparalleled versatility, allowing users to create video wall configurations tailored to each specific need.

🔹 Audio and Video Enhance Features : Audio separation with 3.5mm jack output and support for 180° image flipping in 2x2 mode introduce an additional level of adaptability, allowing for flexible installation and adaptation in situations where the orientation of the display is critical.

🔹 Effortless Integration : The plug and play principle eliminates the need for software drivers, facilitating the integration of the controller into existing operating environments without requiring complex technical interventions.

Areas of Application

The 1x4 HDMI 1080p Video Wall Controller is designed to meet the needs of installers and technicians who work in contexts where visual communication plays a key role, such as command centers, training rooms, retail outlets, and exhibitions.

In-depth Technical Details and Supply Kit

Compatible with HDMI 1.4 and HDCP 1.4 standards, the controller can handle a wide spectrum of video resolutions, giving users plenty of choice for optimizing visual quality. The kit includes all the elements necessary for a quick and reliable installation, allowing immediate post-installation operation.

Dimensions and Design : The compact design and black color of the device allow for easy integration into any environment, maintaining a low but effective profile.

Package Contents : In addition to the controller, the package includes the power supply, a terminal block for secure connections, mounting tabs for installation, and a detailed manual for optimal use of the device.

The use of the 1x4 HDMI 1080p Video Wall Controller not only raises the level of visual presentations but also offers a reliable and customizable solution for managing video walls, helping to create dynamic and engaging visual environments.

Technical specifications

- Support 1 HDMI signal input and 4 HDMI signal output
- Supports resolution up to 1920x1200@60Hz, downward compatible
- Supports 8 splicing (splicing) modes, 2x2, 1x1, 1x2, 1x3, 1x4, 2x1, 3x1 and 4x1 settable via RS-232 or dip switch.
- Supports splicing mode with dip switch switching
- Supports RS232 control instructions to set the splicing mode
- Supports left/right channel audio output separation with 3.5mm jack plug
- Supports 180° image flipping (in 2x2 mode) when top displays are installed upside down
- Plug and play, no need to install drivers

Important:
For an optimal result, the form factor of the source file to be reproduced must be calculated according to the mosaic mode you want to use.

Video signal
Compatibility: HDMI 1.4, HDCP 1.4
Resolutions: 1080p@50/60/30/25/24Hz, 720p@60/50Hz, 576p@50Hz, 480p@60Hz, 1920x1200@60Hz, 1680x1050@60Hz, 1600x900@60Hz, 1600x1200@60Hz, 40x900ç60Hz, 1400x1050@60Hz, 1366x768@60Hz, 1360x768@60Hz, 1280x1024@60Hz, 1280x960@60Hz, 1280x800@60Hz, 1280x768@60Hz, 1024x768@60Hz, 800x600@60Hz, 640x480@60 Hz
